Ultrafiltration (UF) membrane fouling and cleaning methods

A Technical Overview Introduction

Ultrafiltration (UF) membranes play a crucial role in modern water and wastewater treatment processes. With pore sizes ranging from 0.01 to 0.1 microns, UF membranes are effective in removing suspended solids, bacteria, viruses, and macromolecules. However, like all membrane-based systems, membrane fouling remains a key operational challenge, impacting performance, increasing operational costs, and reducing membrane lifespan.

This article explores the major types of fouling in UF membranes and outlines cleaning strategies to restore performance and extend membrane service life.

Types of UF Membrane Fouling

1. Particulate and Colloidal Fouling
   Caused by the accumulation of suspended solids, fine silt, and colloidal particles from feed water. This fouling increases transmembrane pressure (TMP) and reduces permeability over time.
2. Organic Fouling
   Arises from the adsorption and deposition of natural organic matter (NOM) such as proteins, polysaccharides, fats, and oils. Organic fouling tends to form a gel layer on the membrane surface, leading to higher resistance to flow.
3. Biofouling
   Biofouling results from microbial growth and biofilm formation on membrane surfaces. Once established, biofilms are difficult to remove and can significantly increase TMP and decrease flux.
4. Inorganic Scaling (Mineral Fouling)
   Occurs due to the precipitation of sparingly soluble salts (e.g., calcium carbonate, calcium phosphate, iron hydroxide) within the membrane module. Scaling is less common in UF compared to RO but can be problematic under certain conditions.
5. Chemical Degradation
   Although not a type of fouling, membrane degradation due to improper chemical exposure (e.g., high chlorine, extreme pH) must be considered in cleaning protocols.

Indicators of UF Membrane Fouling

• Gradual increase in transmembrane pressure (TMP)
• Decline in membrane permeability or flux
• Increased frequency of backwashing or chemical cleaning
• Elevated pressure drop across the membrane module
• Deterioration in filtrate quality

UF Membrane Cleaning Methods

Cleaning is essential to restore membrane performance. UF systems typically employ two levels of cleaning: physical (routine) and chemical (periodic or as needed).

1. Physical Cleaning

• Backwashing (BW):
  A standard cleaning procedure where filtrate water is flushed in reverse through the membrane to remove accumulated solids from the surface.
• Air Scouring (AS):
  Introduces air bubbles during backwash to enhance cleaning efficiency by creating turbulence and disrupting fouling layers.
• Forward Flush or Drain-Soak:
  A flush or soak with clean water, used before or after backwashing to remove loosened foulants.

Note: Physical cleaning is usually performed every 30–60 minutes during continuous operation to maintain optimal TMP.

2. Chemical Cleaning

When physical cleaning becomes insufficient (e.g., TMP continues to rise), Chemical Enhanced Backwash (CEB) or Clean-In-Place (CIP) procedures are used:

Chemical Enhanced Backwash (CEB):

Short-duration chemical wash integrated into the operation cycle, typically daily or every few days.

• Alkaline CEB (pH 10–11):
  Removes organic and biological fouling. Uses sodium hydroxide (NaOH), often combined with surfactants or chelants.
• Acidic CEB (pH 2–3):
  Targets inorganic scales. Common agents include citric acid or sulfuric acid.
• Oxidative CEB:
  Sodium hypochlorite (NaOCl) is used to remove biofilms. Concentrations must be controlled to avoid membrane damage, especially for PVDF or PES membranes.

Clean-In-Place (CIP):

A more intensive cleaning method used when CEBs are no longer effective.

CIP Procedure:

1. Initial Rinse:
   Flush membranes with permeate or dechlorinated water to remove residual process fluid.
2. Chemical Circulation:
   Circulate cleaning solution (alkaline or acid, depending on fouling type) through the membrane at low pressure for 30–60 minutes.
3. Soak (Optional):
   For heavy fouling, soak membranes in cleaning solution to enhance chemical contact.
4. Final Rinse:
   Rinse with clean water until pH and conductivity return to normal.

Best Practices and Preventive Measures

• Maintain good pretreatment: filtration, coagulation/flocculation if needed.
• Monitor key performance indicators: TMP, flux, and cleaning frequency.
• Select compatible cleaning chemicals based on membrane material and fouling type.
• Schedule regular maintenance cleans before severe fouling occurs.
• Store membranes properly when out of service (e.g., in preservative solution).

Conclusion

Ultrafiltration membrane fouling is an inevitable phenomenon in long-term operation. However, by understanding the fouling mechanisms and applying the appropriate physical and chemical cleaning protocols, plant operators can significantly enhance membrane longevity and system efficiency. Preventive maintenance, combined with optimized cleaning strategies, ensures reliable UF system performance in both municipal and industrial applications.
